DESCRIPTION:
GIRJE Thermic Oil Soils are specially developed Mineral base stock oils blended with selected antioxidants which gives excellent thermal stability and it contributes to low volatility and low vapour pressure. This oil is suited for use in well-designed heat transfer system operating up to 250ºC and280ºC. This oil possesses outstanding thermal and oxidation stability with higher heat transfer rate, which results in superior performance that gives extended trouble free service life to heat transfer system.
PERFORMANCE:
- GIRJE Thermic Oil 500is ideally suited for use in well-designed heat transfer system operating up to 250 ºC to 280ºC
- GIRJE Thermic Oil 600is premium grade heat transfer fluid with low sulphur content & low CCR value. This oil is recommended for operating temperature up to 280 ºC.
PACKING:
Available in 20 / 50 / 210 Ltr.
TYPICAL PROPERTIES: |
Test Properties |
Thermic Oil 500 |
Thermic Oil 600 |
| Appearance | Bright and clear | Bright & Clear |
| Colour | Report | Report |
| Sp. Gr. @ 29.5 ºC | 0.865 | 0.87 |
| K. Viscosity @ 40 ºC | 28 – 33 | 29 – 35 |
| Viscosity Index | 95 MIN | 95 MIN |
| Flash Point | 200 ºC Min | 205 ºC Min |
| Pour Point | -6 ºC Min | -6 ºC Min |
| Copper Corrosion, 100 ºC / 3Hrs | Passes | Passes |
| Total Acid Number mg KOH/gm | 0.05 Max | 0.05 Max |
Note To Purchaser: Our technical advise – whether verbal, in writing or by way of trials – is given in good faith but without warranty, and this also applies where proprietary rights of third parties are involved. It does not release you from the obligation to test the products supplied by us as to their suitability for the intended processes and uses. The application, use and processing of the products are beyond our control and, therefore, entirely your own responsibility. Should in spite of this, liability be established for any damage, it will be limited to the value of thegoods delivered by us and used by you. We will, of course, provide products of consistent quality within the scope of our General Conditions of Sale and Delivery.
EQUIVALENT BRANDS: |
| HPCL | IOCL | BPCL | CASTROL | SHELL | GULF | BALMER LAWRIE | VEEDOL |
| Hytherm500 / 600 | Servotherm Medium | Cabol 32 (TF) | Perfecto HT 32 | H.T Oil S2X | Therm Oil 32 | Prototherm Medium | Thermic Fluid |
